4-86
FACSIMILE
Contents
FAXING THIN ORIGINALS (Slow Scan Mode)
Use this function when you wish to scan thin originals using the automatic document feeder. This function helps prevent
thin originals from misfeeding.
1
Insert the originals face up in the
document feeder tray.
Adjust the document guides slowly.
If the originals are inserted with too much force, they may crumple and misfeed.
2
Enter the destination fax number.
☞
ENTERING DESTINATIONS (page 4-16)
3
Select slow scan mode.
(1) Touch the [Special Modes] key.
☞ SPECIAL MODES (page 4-66)
(2) Touch the [Slow Scan Mode] key so that it is
highlighted.
(3) Touch the [OK] key.
D
C
B
A
D
C
B
A
11
Slow Scan
Mode
Fax/Special Modes
Card Shot
OK
Dual Page
Scan
Quick File
Mixed Size
Original
Erase
Job
Build
File
2in1
Program
Timer
1
2
Original
Count
(3)
(2)
