REPLACING SUPPLIES AND MAINTENANCE
3
To clean the rollers, wipe each roller with a clean
cloth.
Caution
When cleaning the rollers, be careful not to injure your hands.
Do not touch the surface of the roller if your hands are dirty.
• When you replace roller, go to the next step.
• If the dirt is difficult to remove, moisten the cloth with a small amount
of water or neutral detergent, and then wipe with a clean, dry cloth
until no moisture remains.
4
Attach the roller cover on the bypass tray.
(1) Tilt the front of the cover slightly to attach it.
(2) Press the cover onto the bypass tray so that it locks
into place.
(1)
(2)
