5-36
SCANNER/INTERNET FAX
Contents
ENTERING A FILE NAME
The file name can be directly entered when performing a scan transmission.
Touch the [File Name] key. A text entry screen will appear. Enter the file name and touch the [OK] key.
• If the file name is not entered, the settings in the Web page are used.
• For the procedure for entering text, see "ENTERING TEXT" (page 1-44) in "1. BEFORE USING THE MACHINE".
To check the entered file name, touch the [File Name] key in the base screen once again.
USB Mem. ScanFaxInternet Fax PC Scan
Scan
Auto
Scan: Send:
Auto
Text
200X200dpi
PDF
Auto/Grayscale Mono2
PDF
Special Modes
Color Mode
File Format
Resolution
Exposure
Original
File Name
8½x11
