5-56
SCANNER/INTERNET FAX
Contents
4
Specify the orientation in which the
original is placed.
(1) Touch the appropriate [Image Orientation]
key.
If this setting is not correct when sending an image with a
changed ratio, a suitable image may not be transmitted.
(2) Touch the [OK] key.
The ratio used for reduction or enlargement of the original will appear between the "Scan Size" and the "Send Size".
Scan/Original
OK
11x17
8½x11
Scan Size
2-Sided
Tablet
2-Sided
Booklet
Send Size
129%
Image Orientation
(1)
(2)
