This chapter explains how to install the PPD file to enable printing from a
Macintosh and how to configure the printer driver settings.
☞ MAC OS X: this page
(v10.2.8, v10.3.9, v10.4.11, v10.5 - 10.5.1)
☞ MAC OS 9.0 - 9.2.2: page 58
MAC OS X
1
Insert the "Software CD-ROM" into your computer's CD-ROM drive.
Insert the "Software CD-ROM" that shows "Disc 2" on the front of the CD-ROM.
2
Double-click the [CD-ROM] icon ( ) on the desktop.
3
Double-click the [MacOSX] folder.
Before installing the software, be sure to read "ReadMe First". "ReadMe First" is in
the [US-English] folder in the [Readme] folder.
3
SETUP IN A MACINTOSH
ENVIRONMENT
• To use the machine as a printer in a Macintosh environment, the machine
must be connected to a network. A USB connection cannot be used.
• The scanner driver and PC-Fax driver cannot be used in a Macintosh
environment.
The explanations of screens and procedures are primarily for Mac OS X v10.4.
The screens may vary in other versions of the operating system.
