REPLACING SUPPLIES AND MAINTENANCE
3
Remove the toner collection container.
• If the toner collection container is tipped forward too far, it will not be
possible to remove it.
• Do not point the holes down as used toner will spill out.
• Hold the container by both hands and lift it up slowly.
• Do not discard the toner collection container. Place it in a plastic bag
and keep it until your service technician comes to perform
maintenance. Your service technician will collect the toner collection
container.
4
Install the new toner collection container.
Insert the container from above at a slant. (The direction opposite to when you
removed it.)
(1)
(2)
