INSTALLING THE PRINTER DRIVER / PC-FAX DRIVER
This completes the installation.
• After installation, see "CONFIGURING THE PRINTER DRIVER FOR THE
OPTIONS INSTALLED ON THE MACHINE" (page 35) to configure the printer
driver settings.
• Make sure that the port of the installed driver is the same as the port used by
the PCL6 printer driver.
The port used by the printer driver of the machine is indicated by a checkmark
on the [Ports] tab of the printer driver properties window. (In Windows 98/Me,
this is the port selected in [Print to the following port] on the [Details] tab.)
☞ CHANGING THE PORT (page 45)
