2-26

COPIER

Contents

MANUAL RATIO SELECTION (Preset ratios/Zoom)

Touch the [Copy Ratio] key in the base screen of copy mode to select one of three preset enlargement ratios or two

preset reduction ratios (maximum 200%, minimum 50%).

In addition, the zoom keys can be used to select any ratio from 50% to 200% in increments of 1%.

1

Set the ratio.

Touch a preset ratio key and/or the zoom keys to set the ratio.

There are two setting screens. Use the keys to switch

between the screens.

● 1st screen

• Enlargement keys (1 ratio): 129%

• Reduction keys (2 ratios): 64% and 77%

• [100%] key

● 2nd screen

• Enlargement keys (1 to 3 ratios)

200%, any ratio (max. of two)

• Reduction keys (1 to 3 ratios)

50%, any ratio (max. of two)

• [100%] key

• (A) keys

The keys marked (A) can be set to show any ratio using "Add or Change Extra Preset Ratios" in the system settings

(administrator).

• To quickly select a ratio, touch a reduction or enlargement key to select a ratio close to the desired ratio and then

use the zoom keys for fine adjustment.

• The zoom keys can be used to select any ratio from 50% to 200% in increments of 1%.

Touch the key to increase the ratio, or the key to decrease the ratio. (If you continue to touch the /

key, the ratio will change automatically. After 3 seconds, the ratio will change rapidly.)

• As an alternative to touching the keys, you can also directly touch the numeric value display key and

change the value with the numeric keys.

• If the message "Image is larger than the copy paper." appears when an enlargement ratio is selected, the image

may not fit on the paper.

Copy Ratio

OK

Auto Image XY Zoom

129%64%

77%

100%

%

Zoom

100

8½x11

8½x14 8½x11

5½x8½

5½x8½ 8½x11

1

2

Copy Ratio

OK

Auto Image XY Zoom

200%

150%

175%

50%

75%

80%

100%

%

Zoom

100

2

2

(A)
