5-42
SCANNER/INTERNET FAX
Contents
7
Touch the [OK] key.
When storing pre-set text for the subject and file name in the Web pages, up to 80 characters can be entered.
System Settings (Administrator): The Number of File Name/Subject/Body Keys Displayed Setting
The setting for the number of subject keys and file name keys displayed in one screen can be changed to 6, 12, or 18.
Sub: Schedule coordination meeting
Material for planning meeting
Thank you for your continuous support. We have attached sca
Send Settings
OK
Subject
File Name
Body Text
