4-74
FACSIMILE
Contents
7
Touch the [Read-End] key.
If you will continue scanning additional cards, you can touch the [Configure] key to change the exposure, resolution,
scan size, and send size.
• The ratio cannot be specified and "Rotation Sending Setting" cannot be selected.
• This function cannot be used in direct transmission mode or when the speaker is used to dial.
To cancel Card Shot...
Touch the [Cancel] key in the screen of step 4.
Place next original.
Press [Start].
When finished, press [Read-End].
(Pg.No.x)
Configure Read-End
