AR-168N/168L TEST COMMAND, TROUBLE CODES 10 - 4
2 06 RSPF resist clutch operation
check (RSPF RES.CHK)
(Enabled only when RSPF is
set.)
[Function]
When [ENTER/START] key is pressed, the RSPF resist clutch (SRRC) repeats ON for 500ms and
OFF for 500ms 20 times.
[Operation]
08 SPF paper feed solenoid
operation check (SPF SPUS
CHK) (Disabled when set to
OC)
[Function]
The SPF paper feed solenoid (SPUS) repeats ON for 500ms and OFF for 500ms 20 times by the use
of the solenoid drive control Bios.
[Operation]
09 RSPF reverse solenoid
operation check (RSPF
SPFS CHK) (Enabled only
when RSPF is set.)
[Function]
The SPF reverse solenoid (SPFS) repeats ON for 500ms and OFF for 500ms 20 times by the use of
the solenoid drive control Bios.
[Operation]
10 RSPF paper exit gate
solenoid operation check
(RSPF SGS CHK) (Enabled
only when RSPF is set.)
[Function]
The SPF paper exit gate solenoid (SGS) repeats ON for 500ms and OFF for 500ms 20 times by the
use of the solenoid drive control Bios.
[Operation]
3 03 Shifter operation check
(SHIFTER CHK)
[Function]
The shifter is moved back and forth in four reciprocations.
[Operation]
Main
code
Sub
code
Contents Details of function/operation
1) Initial display
02-06 RSPF RES.CHK
EXECUTING...
1) Initial display
02-08 SPF SPUS CHK
EXECUTING...
1) Initial display
02-09 RSPF SPFS CHK
EXECUTING...
1) Initial display
02-10 RSPF SGS CHK
EXECUTING...
1) Initial display
03-03 SHIFTER CHK
EXECUTING...
