AR-168N/168L SPECIFICATIONS 2 - 3
4. SPLC printer
*1: Engine Resolution
*2: Running change
5. Scan function
*1: Running change
6. RSPF
Print speed Max. 15ppm (A4 / with ROPM) / 16ppm (Letter / with ROPM)
First print time 9.6 sec. (without data transfer time)
Duplex Yes
ROPM Yes
CPU None
Memory Share the memory with E-SORT function
Interface RJ45 (10 base) / USB 2.0
Network Internal NIC
Emulation SPLC (JBIG GDI)
MIB support No
Resolution 600dpi *1
Supported OS Win 95 / 98 / Me / NT 4.0 / 2000 / XP
WHQL support Yes *2
Application Status window
Type Flat Bed Color Scanner
Scanning system Document glass / SPF (AR-168N) / RSPF (AR-168L)
Light source 3 CCDs (RGB) sensor scanning by lighting white lamp (2 pcs of CCFL)
Resolution Optical: 600 x 1200dpi
Setting range: 50 - 9600dpi (Preview resolution is fixed at 75dpi)
Originals Sheet type / Book type
Output data R, G, B 1 or 8 bits/pixel / A/D 16bit
Scan range OC / RSPF: 8.5" (297mm) (L) x 14" (431mm) (W)
Original position: Platen: Left center / SPF: Right center
Scan speed OC / SPF: Max. 2.88ms/line (Color/Gray scale), Max. 0.96 ms/line (B & W)
Protocol TWAIN / WIA (Only XP) / STI
Support file format RAW / JPEG
Interface USB2.0
Scanner utility Button Manager / Sharpdesk
Scan key/lamp Yes
Duplex scan No
Supported OS Win 98 / Me / 2000 / XP
Void area No (User settable by PC)
WHQL supported Yes *1
Original capacity 30 sheets (52 to 90g/m
2
) (14 to 23.9 lbs.)
Original size A4 to A5 / 8-1/2" x 14" to 5-1/2" x 8-1/2"
Original replacement speed 12CPM (A4/8-1/2" x 11"Landscape)
Job speed (Tray1,Landscape) Single copy S to S 12CPM
S to D 5.6CPM
D to S 5.5CPM
D to D 5.2CPM
Multi copy S to S 16CPM
D to S 16CPM
Original placement Face up
Original weight 52 to 90g/m
2
(14 - 23.9lbs.)
Mixed feeding No
Original which cannot Thermal papers, originals with punch holes for files, be used folded paper, transparent originals
such as OHP films, stapled or clip used originals with cover up liquid used, Originals with tape
sealed, originals with high level frictional coefficient such as photos or catalogs.
02_SPECI.fm 3 ページ ２００５年１１月１８日 金曜日 午後５時２６分
