3.1 The Diagnostic Test 3 Tests and Diagnostics
3-4 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)
3.1.2 H/W (Hardware) initial information setting tool
The H/W initial information setting tool consists of the following programs.
? Initial configuration
? Region write
? System configuration display
? E2PROM test (MAC/GUID/DMI)
You will need the following equipment to perform some of the programs.
? The Diagnostics Disk (Main T&D)
? A LAN wraparound connector (E2PROM test)
3.1.3 Heatrun test program
The heatrun test starts automatically after the selection.
You will need the following equipment to perform this program.
? The Diagnostics Disk (Main T&D)
