4.23 Fluorescent Lamp 4 Replacement Procedures
Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] 4-85
6. Turn the backlight unit (H) removed face down and remove the two screws (D) and
lamp cover (J).
NOTE: Be careful not to scratch or soil the sheets.
Figure 4-68 Replacing 15.0 Inch Sharp fluorescent lamp (XGA) (7)
(H) Backlight unit
Screw loosening torque: 1.2kg?cm
(J) Lamp cover
(D) Screw
(D) Screw
