2.6 2.5” HDD Troubleshooting 2 Troubleshooting Procedures
Satellite A50S /TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] 2-35
Procedure 4 Diagnostic Test Program Execution Check
The HDD test program is stored in the Diagnostics Disk. Perform all of the HDD tests in
the Hard Disk Drive Test. Refer to Chapter 3, Tests and Diagnostics, for more information
about the HDD test program.
If an error is detected during the HDD test, an error code and status will be displayed. The
error codes and statuses are described in Table 2-5. If an error code is not displayed but the
problem still exists, go to Procedure 5.
Table 2-5 2.5” Hard disk drive error code and status
Code Status
01h Bad command
02h Ad dress mark not found
04h Record not found
05h HDC not reset
07h Drive not initialized
08h HDC overrun error (DRQ)
09h DMA boundary error
0Ah Bad sector error
0Bh Bad track error
10h ECC error
11h ECC recover enable
20h HDC error
40h Seek error
80h Time out error
AAh Drive not ready
BBh Undefined error
CCh Write fault
E0h Status error
EEh Access time out error
DAh No HDD
FFh Data compare error
