4 Replacement Procedures 4.19 Touch Pad
4-56 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)
Installing the Touch pad
The following describes the procedure for installing the touch pad (See Figure 4-39).
1. Place the touch pad switch fitting to bosses.
2. Place the touch pad according to the guide pins.
3. Secure the touch pad with the following screws.
? M2.5x4B THIN BIND screw x6
