3 Tests and Diagnostics 3.30 Sound Test program
Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] 3-87
3.30.3 CD Sound (Standard) test
To execute the CD Sound (Standard) test, press 3 and Enter. Insert the test media (TOSHIBA
TEST CD-ROM or ABEX TEST CD-ROM) or music CD on the market (if the test media can not
be prepared). Following menu appears in the display.
For details on use of test media, refer to (1) Test media (Toshiba-made test media).
For details on use of audio CD on the market, refer to (2) Audio CD.
(1) Test media (Toshiba-made test media)
CD/DVD TEST IN PROGRESS XXXXXXXX
xxxxxxx DIAGNOSTIC TEST VX.XX
[Ctrl]+[Break] ; test end
[Ctrl]+[C] ; key stop
SUB-TEST : XX
PASS COUNT : XXXXX ERROR COUNT: XXXXX
WRITE DATA : XX READ DATA : XX
ADDRESS : XXXXXX STATUS : XXX
01 – Japanese Narration
02 – English Narration
03 – Test Tone A (100Hz – 20Hz)
04 - Test Tone B (400Hz – 3KHz L-R)
Drive # = 0, ATAPI status =00
Command = XX
[[Block address = XXXXXXXX]]
[[Block length = XXXXXXXX]]
Final : Block address = XXXXXXXXX
Subtest01 Japanese Narration
Selected this subtest, narration in Japanese starts and following message appears in
the display.
Play start CD sound !
Press any key <Play stop>.
