3 Tests and Diagnostics 3.13 Hard Disk Test
Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] 3-29
4. The Hard Disk Test message will appear after you respond to the Detail Status prompt.
Select the number of the subtest you want to execute and press Enter. The following
message will appear during each subtest.
HARD DISK TEST XXXXXXX
XXX DIAGNOSTIC TEST VX.XX
[Ctrl]+[Break] : test end
[Ctrl]+[C] : key stop
SUB TEST : XX
PASS COUNT : XXXXX ERROR COUNT : XXXXX
WRITE DATA : XX READ DATA : XX
ADDRESS : XXXXXX STATUS : XXX
The first three digits of the ADDRESS indicate which cylinder is being tested, the fourth
digit indicates the head and the last two digits indicate the sector.
The first digit of the STATUS number indicates the drive being tested and the last two digits
indicate the error status code as explained in table 3-2 of the section 3.18.
Subtest 01 Sequential read
This subtest is a sequential reading of all the tracks on the HDD starting at track 0.
When all the tracks on the HDD have been read, the test starts at the maximum
track and reads the tracks on the HDD sequentially back to track 0.
Subtest 02 Address uniqueness
This subtest writes unique address data to each sector of the HDD track-by-track.
The data written to each sector is then read and compared with the original data.
There are three ways the HDD can be read:
1. Forward sequential
2. Reverse sequential
3. Random
Subtest 03 Random address/data
This subtest writes random data in a random length to random addresses. This data
is then read and compared to the original data.
