4.23 Fluorescent Lamp 4 Replacement Procedures
Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] 4-87
NOTE: Discard the removed tapes. Do not reuse them.
Figure 4-70 Replacing 15.0 Inch Sharp fluorescent lamp (XGA) (9)
(P) Double
-
sided tape 3
(Q) Double
-
sided tape 4
(N) Double
-
sided tape 1
(O) Double
-
sided tape 2
