4 Replacement Procedures 4.23 Fluorescent Lamp
4-92 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)
5. Place the lens sheet (L) and upper diffusion sheet (K) on the backlight unit with light
guide(M).
Figure 4-77 Replacing 15.0 Inch Sharp fluorescent lamp (XGA) (16)
6. Place the LCD panel (I) on the backlight unit (H).
(K) Upper diffusion sheet
(
L) Lens sheet
(M) Light guide
Do not make any sheet over
the edge of P-chassis.
