4 Replacement Procedures 4.23 Fluorescent Lamp
4-84 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)
5. Turn the LCD module face up and remove the LCD panel (I) from the backlight unit
(H).
CAUTION: Wear finger sacks or gloves during the work not to soil or scratch the LCD
panel or backlight unit.
Figure 4-67 Replacing 15.0 Inch Sharp fluorescent lamp (XGA) (6)
(H) Backlight unit
(I) LCD panel
